Features:
This machine a specially-designed point-cut rolling dual-purpose for vest & flat bags, is controlled by a computer, the step setting length system reduces the sealing-cutting dimensions errors, and the installation of photoelectric eyes track help make the position of figure of printing bags accurately, the computer numerical control can be selected to adjust the length of bag the machine will automatically stop and sound a warning if there is something wrong with the printing bags. it is an ideal bag maker for producing fresh-resisting bag, rubbish bag and flat placket with the merits of easy operation steady function and good sealing
Usage:
This bottom sealing machine is suitable for making natural color and color-printed plastic bags. If the film without color-code, the machine can be operated with double production lines The high and low density polyethylene film bags produced by the machine are applied to shopping in the supermarkets, shops and markets.
Technical Parameters:
|
Model |
ZDB-500 |
ZDB-600 |
ZDB-700 |
ZDB-800 |
|
Max. Width of bag-making(mm) |
400 |
500 |
600 |
700 |
|
Max. length of bag-making(mm) |
1200 |
1200 |
1200 |
1200 |
|
Bag-making Thickness(mm) |
0.008-0.10 |
0.008-0.10 |
0.008-0.10 |
0.008-0.10 |
|
Speed of bag-making(pc/min) |
40-120 |
40-120 |
40-120 |
40-120 |
|
Power of motor(kw) |
1.1 |
1.1 |
1.5 |
1.5 |
|
Electric Heating power |
1.2 |
1.6 |
2 |
2.2 |
|
Packing Dimensions(L× W×H)mm |
3400×1200×1700 |
3400×1300×1700 |
3400×1300×1700 |
3700×1500×1700 |
|
Packing weight(kg) |
1000 |
1060 |
1180 |
1220 |
|
Machinery dimension (L×W×H)mm |
3300×110×1500 |
3300×1200×1500 |
3300×1300×1500 |
3300×1400×1500 |
|
Machinery weight (kg) |
800 |
850 |
900 |
1000 |
|
