Specifications:
Automatic non-woven hand ring bag making machine is put behind the vice material, the width of the substrate is exactly equal to the length of the portable bar. It’s working procedure exactly have a computer to control, the speed is generally manual work, we only do a few times more, can put two roll film material automatically make it a beautiful decorative pattern lines article, civilian right colleagues to the bag, can achieve the yield of backup straight forward.
The machine adopts PLC control, man-machine interface touch screen operating is simple, easily modify the parameters, accurate feeding step motor, cold-cut edges cut material without burr, high-frequency ultrasonic heat sealing strong aesthetic 30-80 grams of non-woven fabric can produce a variety of soft handle shopping bags, gift bags, etc.
Main Technical Parameter:
|
Type |
WFHB-600 |
WFHB-800 |
|
Cutting speed (pcs/min) |
10-25 |
10-25 |
|
Bag width (mm) |
350-580 |
350-780 |
|
Material Thickness (GSM) |
30-120 |
30-120 |
|
Power (V) |
220 |
220 |
|
The total power (KW) |
3.0 |
3.5 |
|
The weight of the machine (kg) |
400 |
450 |
|
The weight of the machine and packaging (kg) |
450 |
500 |
|
Overall Dimension (LxWxH) (mm) |
1450х1400х1300 |
1650х1500х1300 |
|
