Characteristics:
1.The main motor adopts imported converter to govern in a staples way.
2.Feeding and unwind are controlled through magnetic powder brake and clutch (Japanese Mitsubishi auto tension controller).
3.Unwind system is controlled by auto-rectify sensor.
4.Adopt ceramic mesh distributor roller, which is characterized by durability, wear resistance, and corrosion resistance. The doctors can be used, which is more efficient for reducing the times for changing in order to increase the production efficiency.
5.The printing unit cans register in 360 degrees. Each printing unit can independently gear and loosen to have the units continue printing.
6.The printing units are all equipped with a group of infrared dryers respectively.
7.Each IR dryer device of printing unit can interchange of UV dryer device.
8.The rolling device is adopted clipping device with air-expansion core shaft.
9.The inking roller can automatically fall off at stoppage and transfer at low speed in order to keep the ink from being dry and solid.
10.The roll feeding, printing, polishing, auto infrared drying, laminating and rolling can be processed in one processing. It is characterized by wide application, non-population of printing ink and fast drying, quick printing. So it is an ideal printing machine for the commercial bill to print high-Graded free adhesive trademark.
Main technical parameters：
|
Model type |
RY320-B |
|
Printing speed |
60 folds m/min |
|
Be printed color |
5 Color |
|
Web maximum width |
320mm |
|
The largest printing width |
310mm |
|
Roll diameter |
600mm |
|
Rolling diameter |
550mm |
|
Printing perimeter |
175-320mm |
|
Alignment accuracy |
±0.1mm |
|
The dimension (L×W×H） |
2000×1500×3000mm |
|
Weight machines |
about2000kg |
|
Power |
380v/ACThree Phase 50H |
|
Total power |
6.8kw(Non-UV) |
|
