Some print production：
1. Hob die-cutting equipment magnetic roller
2. Flexible ultraviolet radation glazing equipment
3. Ultraviolet radation UV drying equipment width of lamp chest is within 140mm
4. CCD camera
Characteristics:
1. Adopt paper shuttling mode, merely one block roller could finish without considering the size of paper.
2. Adopt no-axle control system to control every servo motor of each roll in printing driver accurately, which make the optimization control to machine state.
3. Adopt color code photoelectric sensing technology to automatically overprint first so as to improve the precision of overprint and shorten the prepare time of pre-print.
4. Adopt optimum ink roller collocation and speed, improve the printing quality.
5. First design the printing pressure regulator, which makes it needn’t to regulate pressure while changing the block roller, and can improve efficiency consumedly.
6. The supply of ink and the speed of the machine will change proportionally, makes the printing result better.
7. Troubles of the machine would be shown on the screen automatically, which will shorten the repair time.
8. Paper winding and feeding, printing, overprinting, circuit press and circuit mould cutting, waste discharging, rewinding will be finished together.
9. This equipment most suits prints the multi-variety Different batch quantity, is printing the Mid-grade and upscale self-adhesive trademark factory most ideal machine.
Main technical parameters:
|
Model type |
SUPER-320 |
|
Web maximum width |
320mm |
|
The largest printing width |
300mm |
|
The maximum printing speed |
60m / min |
|
Color printing |
2-9color |
|
Printing length |
50-245mm |
|
Roll diameter |
700mm |
|
Rolling diameter |
700mm |
|
The dimension |
6800×1600×1400 |
|
Weight machines |
6000kg |
|
Power |
200V/AC.Three Phase 50/60H 50A 17.3KVA |
|
