Characteristics:
The
machine speed: advanced oil system, oil closure of small, short molding cycle.
Control
circuit: the turntable rotates quickly advanced operation, and adjustable
speed, rotation: slow start fast start-smooth deceleration-slow stop; the whole
operation time is short, smooth rotation.
Accurate
positioning: multiple positioning Modes; in addition to the precise positioning
of the circuit, the use of hydraulic mechanical limit and taper locator device,
in order to achieve the highest accuracy per reciprocating operation.
Parameter:
|
Type
|
HDTY1200-2R
|
|
INJECTION UNIT
|
|
|
Screw
Diameter, mm
|
42
|
|
Injection
Pressure, Kg/cm2
|
2631
|
|
Theoretical
Shot volume, cm3
|
305
|
|
Max. Shot
Weight, g/Oz
|
272/9.6
|
|
Injection
Rate, cm3/sec
|
103
|
|
Temperature
Control, ZONE
|
4
|
|
Material
Hopper Capacity, L
|
30
|
|
CLAMPING UNIT
|
|
|
Clamping
Force, T
|
120
|
|
Opening Force,
T
|
16
|
|
Mold
dimensions, mm
|
600*400
|
|
Min Mold
Height, mm
|
450
|
|
Opening
Stroke, mm
|
300
|
|
Max. Open
Daylight, mm
|
750
|
|
Ejector Force,
T
|
4.6
|
|
Ejector stoke,
mm
|
75
|
|
POWER UNIT
|
|
|
Max. Hydraulic
Pressure, Kg/cm2
|
140
|
|
Pump Output, L
|
480
|
|
Pump Motor
Power, kw
|
15
|
|
Barrel Heating
Power, kw
|
10.4
|
|
Total Wattage,
kw
|
25.4
|
|
GENEARL
|
|
|
Machine
Weight, t
|
7
|
|
Machine Dimensions(L*W*H),
m
|
2.3*1.7*3.8
|
|
Round Set
Diameter, mm
|
φ1224
|
|
