Characteristics
1. HENGDA
advanced high oil system, oil cut-off small, short molding cycle. The control
circuit is advanced, stable.
2. In
addition to precise positioning of precision positioning of the circuit, the
use of hydraulic mechanical limit device, in order to achieve the highest
accuracy per reciprocation operation.
3. The
Taiwan HONGXUN computer control, color screen, CPU operation speed, the action
fast conversion speed, smooth transition.
4. The
configuration of double electronic ruler, with opening and closing of mold,
injection, feeding motion stroke control precision, accuracy reach mm, can be
set in the computer. To achieve the advantages of the standard management etc.
5. Security:
machine with three surface protection, the work surface configuration Taiwan
YANGMING grating, so that the overall safety is reliable.
Parameter:
|
Type
|
HDTYU850-2R
|
|
INJECTION UNIT
|
|
|
Screw
Diameter, mm
|
32
|
|
Injection
Pressure, Kg/cm2
|
2180
|
|
Theoretical
Shot volume, cm3
|
144
|
|
Max. Shot
Weight, g/Oz
|
129/4.5
|
|
Injection
Rate, cm3/sec
|
68
|
|
Temperature
Control, ZONE
|
3
|
|
Material
Hopper Capacity, L
|
30
|
|
CLAMPING UNIT
|
|
|
Clamping
Force, T
|
85
|
|
Opening Force,
T
|
13.5
|
|
Min Mold
Height, mm
|
200
|
|
Opening
Stroke, mm
|
400
|
|
Max. Open
Daylight, mm
|
600
|
|
Ejector Force,
T
|
2.7
|
|
Ejector stoke,
mm
|
50
|
|
SLIDING
MODE UNIT
|
|
|
Round Set Diameter, mm
|
φ1000
|
|
POWER UNIT
|
|
|
Max. Hydraulic
Pressure, Kg/cm2
|
140
|
|
Pump Output, L
|
260
|
|
Pump Motor
Power, kw
|
11
|
|
Barrel Heating
Power, kw
|
4.5
|
|
Total Wattage,
kw
|
15.5
|
|
General
|
|
|
Machine Weight, T
|
3.9
|
|
Machine
Dimensions(L*W*H), m
|
2.7*1.4*2.5
|
|
