Application:
Big bottles in multi-row without trays such as drinking bottles, pure water bottles, beer bootles, etc.It can be conntected and work with auto filling machine.
Main technical parameters:
|
Model |
BXC-800A |
|
Sealing type |
sleeve sealing |
|
Electric Power |
380V/50-60Hz/3phase |
|
Max product size(mm) |
420×300×320 |
|
Packing capacity(pieces /minute) |
20 |
|
Film type |
polyethylene (PE) film |
|
Max film size |
630×280 |
|
Rated power consumption(kw) |
20.5 |
|
Infeed conveyor length(mm) |
2300 |
|
Tunnel oven size(mm) |
1800×600×400 |
|
Tunnel conveyor speed(m/min) |
variable,controlled by frequency converter, 15 |
|
Tunnel conveyor |
steel mesh belt conveyor |
|
Working height(mm) |
780-850 |
|
Air pressure(MPa) |
≤0.5 |
|
PLC |
SIEMENS S7 |
|
Sealing system |
Permanently tempreture and heated system with easy-exchangeable sealing blade without odorous |
|
Operating interface |
Eview Eview displayer |
|
Machine material |
carbon steel | |
